Applications
Suitable for processing high-performance fibers such as glass fiber, carbon fiber, and more. The produced multi-axial carbon fiber fabric and fiberglass cloth are widely used in aerospace, aviation, wind turbine blades, shipbuilding, construction, automotive, sports goods, and other fields.
Features
- Production of multiaxial non-crimp fabrics with parallel weft insertion system in 0° and 90°.
- The weft yarns can be fed-in online or offline.
Specifications
Needle type Compound needle
Gauge E5, E6, E7, E10, E12, E14
Number of guide bars 2 guide bar +1 ST
1 guide bar +1 weft knitting bar
2 guide bar +1 weft knitting bar
Working width 50"/101"
Weft laying system Adjustable between +20° and -20°
Max. speed 800 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 30500×6200×3100 | 189.1 | 60000 | 36.6 | |
| 30500×7500×3100 | 228.75 | 80000 | 42.7 |
