Processing materials
Weaving plain fabrics and mesh fabrics made from natural fibers, synthetic fibers, metal wires, aerospace-grade fiberglass, and other materials.
Applications
Shoe, apparel textiles, home textiles, luggage, linings, etc.
Features
- High speed net knitting machine utilizes an oil-immersed cam-linkage mechanism.
- Net knitting machine uses short latch needles for fast operation and high fabric output speed.
- The warp knitting machine adopts an adjustable needle bar swing arm form.
- The high speed net knitting machine is equipped with electronic yarn let-off (EBA), electronic take-up, and electronic batching functions.
Specifications
Needle type Block latch needle
Gauge E6-E24
Number of bars 2-6 bars
Working width 90"/138"/175"/240"/260"
Max. speed 700 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 3000×2350×2800 | 7.05 | 7500 | 9.5 | |
| 3560×2350×2800 | 10.86 | 8000 | 10.25 | |
| 5640×2350×2800 | 12.78 | 8000 | 11.25 | |
| 8050×4850×3300 | 39.04 | 10000 | 16.25 | |
| 10800×2300×2600 | 41.47 | 12000 | 18.25 |
