Applications
Artificial lawns and turf fabrics used in running tracks, playgrounds, and shielding nets.
Features
- Artificial lawn warp knitting machine uses an oil immersed cam-linkage mechanism and a swinging knock-over comb bar.
- Raschel warp knitting machine comes with a special latch needle and an open sinker system.
- Yarn supply for the pile bars from creel.
- The warp knitting machine has functions of electronic yarn let-off and electronic fabric take-up.
Specifications
Needle type Individual latch needle
Gauge E3, E6, E9
Number of bars 5 bars
Distance between knocking-over bar 20-100mm
Working width 100"/110"
Max. speed 300 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| GE2399-100" | 4000×6050×3400 (excluding creel) | 24.2 (excluding creel) | 8500 (excluding creel) | 8.25 |
