Applications
Plush fabrics used in plush toys, blankets, apparel and home upholstery.
Features
- Medium pile plush fabric warp knitting machine uses an oil immersed cam-linkage mechanism.
- The spacer fabric warp knitting machine comes with fixed ground bars.
- Plush fabric warp knitting machine comes with a steel wire put into eyelet of the sinker to prevent close circle.
- The yarn let-off device controls the 2 rollers for positive yarn feeding.
- The plush has a pile height of 5-25mm.
Specifications
Needle type Individual latch needle, block latch needle
Gauge E16, E18, E22
Number of bars 5 bars
Distance between knocking-over bar 10-50mm
Working width 90"/100"/110"/138"/150"/158"/170"/192"
Max. speed 800 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 3700×6050×3750 | 22.4 | 8000 | 10 | |
| 4000×6050×750 | 24.2 | 8500 | 10 | |
| 4350×6050×3750 | 26.3 | 9350 | 11 | |
| 5100×6050×3750 | 30.9 | 12000 | 12.5 | |
| 5100×6050×3750 | 30.9 | 12500 | 14.5 | |
| 5300×6050×3750 | 32.1 | 12500 | 15.5 | |
| 6100×6050×3750 | 36.9 | 14000 | 15.5 | |
| 6500×6050×3750 | 39.3 | 16000 | 17.5 |
